Stinger 20cc RE Rear Exhaust Gas Engine
The Stinger 20cc RE is a two-stroke gasoline engine designed for RC airplanes. Its rear exhaust layout helps accommodate narrower cowls, including those found on many warbirds. A beam mount makes it a practical choice for compatible aircraft being converted from glow power to gasoline.
This engine features a rear-mounted Walbro pumper carburetor and electronic CDI ignition with automatic timing advance. Stinger rates the 20cc RE at up to 2.8 hp (2.1 kW) and recommends a range of two-blade propellers from 14 × 10 through 17 × 6. Check your airplane’s mounting dimensions, cowl clearance, and propeller requirements before installation.
Highlights
- 20cc (1.22 cu in) two-stroke gasoline RC airplane engine
- Rear exhaust configuration suited to installations with limited side clearance
- Beam mount for compatible glow-to-gas conversions
- Rear-mounted Walbro pumper carburetor
- Electronic DC-CDI ignition with automatic timing advance
- Air-cooled engine with NGK CM6-type spark plug
- Muffler and ignition module included
Manufacturer Specifications
| Model | Stinger 20cc RE |
|---|---|
| Gator RC SKU | STNG-20-RE |
| Engine type | Two-stroke gasoline RC airplane engine |
| Displacement | 1.22 cu in (20cc) |
| Bore × stroke | Approx. 1.26 × 0.94 in (32 × 24 mm) |
| Maximum rated output | 2.8 hp (2.1 kW) |
| Manufacturer-listed speed range | 1,500–10,800 rpm |
| Manufacturer-listed idle speed | 1,800 rpm |
| Carburetor | Walbro pumper carburetor |
| Ignition | Electronic DC-CDI with automatic timing advance |
| Ignition power supply | 7.4–14V, per manufacturer listing; verify the requirements of the ignition module supplied with your engine |
| Spark plug | NGK CM6 type or equivalent |
| Recommended two-blade propellers | 14 × 10, 15 × 8, 16 × 6, 16 × 8, or 17 × 6 |
| Manufacturer-listed break-in propeller | 16 × 8 two-blade |
| Cooling | Air-cooled |
| Engine weight | Approx. 1.37 lb (620 g) |
| Muffler weight | Approx. 2.08 oz (59 g) |
| Ignition module weight | Approx. 4.4 oz (125 g) |
Fuel and Ignition
The manufacturer specifies premixed gasoline and two-stroke oil. Its current listing recommends a 32:1 gasoline-to-oil ratio for conventional oil or 40:1 for synthetic oil. Follow the manual included with your engine for fuel, break-in, and operating instructions.
The manufacturer lists a 7.4–14V ignition power supply and specifically advises not powering the ignition through a BEC, iBEC, or uBEC. Verify your ignition module and battery compatibility before connecting power.
What’s Included
- Stinger 20cc RE engine
- Electronic CDI ignition module
- Muffler
- Spark plug
- Gaskets and bolts
- Throttle arm extension
- Engine manual
Additional Items Required
Gasoline, suitable two-stroke oil, an ignition battery, and a compatible propeller are required to operate the engine. These items are not listed by the manufacturer as part of the engine package.
Replacement Parts
Keep your engine flying with our Stinger 20cc engine parts. We also carry a Stinger spark plug, spinner adapter nut, and Walbro carburetor. Check the individual part listing and your engine before ordering to confirm compatibility.
