CA Model Karma V2 F3A Monoplane Special order

CA Model Karma V2 F3A Monoplane pricing includes shipping worldwide

 These are custom-made to order. Allow an average of 8 weeks for delivery.

Introducing the all-new CA Model Karma V2

Karma V2 Features

Designed  for Mariano Gostanian
Elliptical shaped wing
The elliptical shaped horizontal stabilizer
Composite fuselage fully painted in a beautiful color scheme
Covered flying surfaces with unmatched quality
Plug-in wings, and stabs with carbon fiber tube
fiberglass rudder
T can fiberglass

Made in Argentina

Levels of Completion

ARF (almost ready to fly) in our standard color, including accessories bag
Special: You pick the colors and layout and we will process it for you. The average cost for a custom scheme is $250. Call for details.

Color Schemes

Mariano Gostanian color scheme (standard color)
Available on a limited basis, we produce a small run of Custom painted & Custom covered

Karma Specifications

Dimensions
Length: 74.80 in (1990 mm)
Wingspan: 73.62 in (1830 mm)

Weight
Net Weight:  (2400 grams) Included landing gear and wheel pants
Gross Weight:  (4800-5000 grams)

Construction
Fuselage rudder and T canalizer: Vacuum Fiberglass, Divinycell, full painted
Wings: Balsa built-up, covered film
Horizontal Stabilizer: Balsa built-up, covered film


Power
V4 Contra (Nose made to fit custom order)

Dualsky 10S or 12S motors (Sold here)

Himax 6330Pro

Available for Contra drive
ESC: 80 HV or above
Spinner Size: 90 mm

Propeller recommended
Falcon 21x13.5
PT Model 21x13

All sold here

Included Hardware
Lightweight wheels with axles
Wheel pants
Carbon fiber main landing gear

Tailwheel assembly
Stab adjusters

Wing adjusters
Control horns (6)
Battery tray with carbon rods
Servo rudder tray
Wing Tube (carbon fiber)
Stab Tube (carbon fiber)


Servos (required)
Ailerons: (2) standard size
Elevator: (2) mini size
Rudder: (1)  standard size

 Inquire for guidance.

Setups & Tips
Wing Incidence: + 0.8 degree
Stab Incidence: 0 degreesT

T can fixed incidence
