Castle Creations Talon 15 ESC 15A 4S Brushless Speed Controller with 8A BEC | CSE010-0129-00
Couldn't load pickup availability
Castle Creations Talon 15 ESC – 15A Brushless with 8A Peak BEC
The Castle Creations Talon 15 is a compact, lightweight electronic speed controller designed for foam aircraft, park flyers, micro helicopters, sub-micro helicopters, and small electric models. Supporting 2S to 4S LiPo batteries and delivering 15 amps of continuous current, the Talon 15 offers Castle reliability in a very small package.
The standout feature of the Talon 15 is its oversized built-in BEC. This compact ESC provides up to 8A peak and 3A continuous BEC output at 5.5V, giving small aircraft and helicopter setups reliable receiver and servo power without requiring a separate receiver battery in many installations.
🚀 Target Applications:
- Foam Aircraft & Park Flyers
- Micro & Sub-Micro Electric Helicopters
- Small Sport Aircraft & Electric Trainers
- Lightweight Electric Power Systems Up To 4S and 15A
Key Features
- Compact Voltage Range: Handles 15A continuous current while supporting 2S up to 4S LiPo input ceilings (16.8V Max).
- Miniature Muscle BEC: Oversized switching BEC yields 8A peak / 3A continuous output to protect against voltage brownouts on modern digital micro servos.
- Live Telemetry Output: Telemetry capable interface lets compatible radio systems track and monitor critical power system parameters in real time.
- Featherweight Footprint: Micro structural casing weights only 0.25 oz (7.2g) with wires to maximize space in ultra-tight balsa, foam, or heli frames.
- Castle Link Tuning: Fully programmable via a Windows PC for throttle tuning, brake adjustments, and motor timing settings (free coupon for a Castle Link USB Adapter included).
⚙ Castle Link Programmability:
Fine-tune your aircraft's performance envelope by adjusting advanced software settings (Castle Link USB adapter coupon included):
- Throttle Response Tuning: Tailor linear motor acceleration parameters.
- Brake Adjustments: Custom stopping force tweaks for folding propeller systems.
- Motor Timing Configurations: Optimize electronic timing to maximize outrunner motor efficiency.
View Technical Specifications
| Continuous Current: | 15A |
| Input Voltage Range: | 2S–4S LiPo |
| Maximum Input Voltage: | 16.8V |
| BEC Voltage Output: | 5.5V Regulated Fixed |
| BEC Amp Rating: | 8A Peak / 3A Continuous |
| Telemetry Capable: | Yes (Accessories sold separately) |
| Data Logging / Aux Wire: | No |
| Dimensions (L x W x H): | 1.10 x 0.58 x 0.32 in (27.9 x 14.7 x 8.1 mm) |
| Weight (With Wires): | 0.25 oz (7.2 g) |
| Weight (Without Wires): | 0.12 oz (3.4 g) |
| Connectors: | Bare wire leads |
| Factory Warranty: | 1-Year manufacturing defect coverage |
📦 Package Includes:
- 1 x Castle Creations Talon 15 ESC
- 1 x Castle Link USB Adapter Coupon
- 1 x Factory Instruction Documentation
💡 Modeler’s Tips
The Talon 15 is exceptionally unique because it packs a true switching BEC into an ultra-narrow profile. Most sub-20A speed controllers utilize linear BECs that get dangerously hot on 3S or 4S layouts; the Talon 15 stays remarkably cool while delivering an outstanding 8A peak burst to keep your sub-micro digital servos fully powered during aggressive tracking maneuvers.
