Castle Creations Castle Link V3 USB Programming Kit
The Castle Creations Castle Link V3 USB Programming Kit allows you to program compatible Castle Creations ESCs, BECs, telemetry accessories, and other Castle Link-capable products from a Windows PC. Instead of using transmitter stick programming, Castle Link gives you a simple software-based interface for viewing settings, adjusting performance, updating firmware, and accessing data logs on compatible Castle products.
Castle Link V3 uses Castle Link Classic software for programming compatible Castle products, helping you bypass confusing transmitter stick programming loops entirely.
⚙ Broad System Compatibility:
This V3 programming interface is explicitly recommended for configuring the following Castle hardware families:
- Air Controllers: Castle Talon, Phoenix, and Thunderbird ESC lines.
- Surface & Marine: Castle Mamba, Sidewinder, and Hydra speed controllers.
- Power & Telemetry: Castle BEC Pro, external switching regulators, and telemetry link accessories.
Key Features
- Windows Software Interface: Replaces manual programming with a clean, visual software suite to view and adjust current device parameters.
- Advanced Tuning Access: Easily configure low-voltage cutoffs, propeller brake strength, drag brakes, motor timing, torque limiting, and governor profiles.
- Onboard Data Log Access: Download and review stored power telemetry profiles (voltage, heat, amp draw, RPM) from logged-data capable ESC lines.
- Micro-B USB Hardware: Modern V3 physical layout utilizes a standard Micro-B USB connection port on the adapter board.
- BEC Adjustability: Allows user-targeted output voltage programming on compatible standalone and integrated Castle BEC modules.
📋 Step-by-Step Workbench Setup Guide:
- Download and install the official Castle Link Classic software installer from Castle Creations.
- Connect the physical Castle Link V3 interface adapter to your compatible Castle device lead.
- Plug the included USB cable from the adapter board directly into an open Windows PC port.
- Open your Castle Link software package to view, tweak, test, and save your custom hardware configurations.
View Technical Specifications
| Product Model: | Castle Link V3 USB Programming Kit |
| Castle Part Number: | 011-0119-00 |
| Gator RC / CSE Number: | CSE011011900 |
| USB Hardware Port: | Micro-B USB Connection |
| Required Software Platform: | Castle Link Classic Suite |
| Computer OS Compatibility: | Windows PC |
| Data Logging Download: | Supported (Requires matching data-capable Castle ESC) |
*Note: Available programming features and parameters will adapt dynamically based on the exact Castle hardware module actively plugged into the interface.
📦 Package Includes:
- 1 x Castle Link V3 USB Programming Adapter
- 1 x Interface USB Cable
💡 Modeler’s Tips
When linking your speed controller to the V3 card, ensure the ESC orientation signal wires align with the marked polarity pins on the adapter board. If your ESC does not feature a built-in BEC (such as the high-voltage Opto Phoenix Edge series), remember that you will need to plug a small external receiver battery or receiver power source into the ESC circuit to power the processor chip before the software can scan the hardware settings.
