Gator RC Deluxe HD Rudder Horn System – Aluminum Linkage Mount

Gator RC Deluxe HD Rudder Horn System – Aluminum Linkage Mount

The Gator RC Deluxe HD Rudder Horn System is a heavy-duty rudder linkage solution for RC airplanes that need a strong, precise, and reliable control setup. This system uses an M4 × 100mm threaded rod that passes through the rudder, with M3 × 32mm ball links and horns for secure linkage connection.

Key Features

• Heavy-Duty Rudder System: Designed for high-load rudder applications
• Through-Rudder Rod Design: M4 × 100mm rod passes through the rudder for a strong mechanical connection
• M3 Ball Link Setup: Includes M3 × 32mm ball links and horns for precise linkage movement
• Aluminum and Steel Components: Built for strength, rigidity, and durability
• Adjustable Setup: Allows spacing and alignment adjustment during installation
• Ideal for Pull-Pull or Pushrod Linkage: Suitable for larger RC airplane rudder control systems

Specifications

• System Type: Deluxe HD Rudder Horn System
• Main Rod: M4 × 100mm threaded rod
• Main Rod Function: Passes through the rudder
• Ball Link Size: M3 × 32mm
• Horn Thread Size: M3
• Material: Aluminum and steel components
• Application: Rudder control linkage
• Compatible Linkage Style: Pull-pull cable systems or pushrod linkage setups

What’s Included

• 1 × M4 × 100mm threaded rudder rod
• 2 × Aluminum spacer cones
• 2 × HD rudder horn arms
• 2 × M3 × 32mm ball links
• Mounting nuts and fasteners

Required to Complete

• Pull-pull cables or pushrod linkage
• Rudder servo and compatible servo arm
• Airframe/rudder prepared for through-rod installation
• Threadlock for metal-to-metal hardware

Best For

• Medium to large RC airplanes
• Gas and giant-scale aircraft
• Pull-pull rudder systems
• High-load rudder control applications
• Builders replacing basic rudder horns with a stronger adjustable system

Fitment & Compatibility

• Designed for rudders that allow an M4 through-rod installation
• Uses M3 × 32mm ball links and horns for linkage connection
• Works with pull-pull cable setups or rigid pushrod applications
• Best suited for aircraft where a strong, adjustable rudder horn system is preferred

Installation Notes

• Install the M4 × 100mm rod through the rudder and center the system before tightening hardware
• Adjust the aluminum spacer cones to align the horn arms evenly on both sides of the rudder
• Use proper cable tension in pull-pull setups to eliminate slack
• Use threadlock on metal fasteners to help prevent loosening from vibration
• Check rudder movement through full travel to confirm there is no binding

Why Use a Deluxe HD Rudder Horn System?

A through-rudder horn system provides a stronger and more adjustable linkage connection than many basic surface-mounted rudder horns. The M4 rod passes through the rudder for strength, while the M3 ball links help provide smooth, precise control movement for pull-pull or pushrod setups.

This is an easy to install adjustable rudder horn system
The washers that goes against the rudder on both side swivels to fit the taper of the rudder.
Great for 25% and up, sized planes.
The ball links are slop and friction free to make a very slick and good looking installation.
Comes with all the hardware shown in the picture.
