Gator RC Spring Canopy Latch, Center Pull, 3mm Pin, Lightweight RC Airplane Hatch Latch

In stock
SKU: GRC-CL-29
(0)
$2.62
Sale $3.75 $2.62

Gator RC Spring Canopy Latch – Lightweight Center-Pin Latch for RC Aircraft

The Gator RC Spring Canopy Latch is a lightweight, spring-loaded latch designed to securely hold canopies, battery hatches, radio compartments, belly pans, and access panels on RC aircraft. The simple design provides positive engagement while allowing quick, tool-free access for battery changes and maintenance.

When installed, the spring-loaded brass locking pin automatically extends to secure the hatch. To release, simply press the brass locking pin inward against the spring, allowing the hatch to open. Releasing the pin automatically locks the hatch again.

Ideal For:
• RC Airplane Canopies
• Battery Hatches
• Radio Compartments
• Belly Pans
• Engine Access Doors
• Custom Aircraft Projects

Features

  • Lightweight spring-loaded canopy latch
  • Automatic locking action
  • Press-in release pin for quick canopy removal
  • Brass locking pin with steel release pin
  • Compact design weighs only 2 grams (0.07 oz)
  • Simple installation
  • Ideal for electric, glow, and gas-powered RC aircraft
  • Excellent for new builds or replacement installations
  • Provides secure retention during flight

How It Works

  1. The spring pushes the brass locking pin outward to lock the hatch securely.
  2. To open the hatch, press the brass locking pin inward against the spring.
  3. Lift the hatch or canopy while the pin is retracted.
  4. Closing the hatch allows the spring-loaded pin to extend automatically, locking it in place.
Modeler's Tip:
These latches are commonly used for canopies, battery compartments, radio access doors, and removable engine hatches. Their lightweight design makes them an excellent choice for everything from park flyers to giant-scale aircraft.

Specifications

Body Material Engineering Plastic
Locking Pin Material Brass
Release Pin Material Steel
Body Size 25.4 × 15.8 mm (1.00 × 0.62")
Spring-Loaded Locking Pin Length 38 mm (1.50")
Release Pin Height 31.4 mm (1.24")
Locking Pin Diameter 3 mm (0.12")
Weight 2 g (0.07 oz)
Application Canopies, Battery Hatches, Radio Compartments, Belly Pans, Engine Access Doors

Package Includes

  • 1 × Spring Canopy Latch Assembly

Installation Guide

  1. Install the latch body securely inside the fuselage or hatch structure using appropriate fasteners or adhesive.
  2. Align the brass locking pin with the receiving hole in the canopy or hatch.
  3. Test the movement of the locking pin to ensure smooth operation before final installation.
  4. Verify the hatch closes fully and the spring-loaded pin automatically engages.
  5. Perform a final fit check before flight.
Important: Always verify the latch is fully engaged before every flight. A properly installed latch helps prevent accidental canopy or hatch opening during flight.
