Gator RC XT30U Connector Set – Male & Female, 1 Pair
The Gator RC XT30U Connector Set provides a compact, reliable electrical connection for RC batteries, electronic speed controllers, charger leads, electric aircraft, drones, and other small electric power systems.
Each package contains one complete pair: one male XT30U connector and one female XT30U connector. Gold-plated brass contacts help provide low electrical resistance, while the heat-resistant nylon housings offer a secure, polarized connection.
Package Quantity: 1 male connector + 1 female connector = 1 complete pair
Features
- Compact XT30U-style power connector set
- Includes one male and one female connector
- Gold-plated brass electrical contacts
- Low-resistance electrical connection
- Heat-resistant nylon connector housings
- Polarized design helps prevent reverse-polarity connections
- Compact and lightweight for smaller electric power systems
- Suitable for batteries, ESCs, charger leads and custom wiring
- Reusable solder-type connector design
Common Applications
- RC airplane battery connections
- Electronic speed controller connections
- LiPo battery packs
- Battery charging leads
- FPV drones and multirotors
- Small electric helicopters
- Robotics and custom electronics projects
Specifications
| Connector Type | XT30U |
| Package Quantity | 1 Pair |
| Connectors Included | 1 Male and 1 Female |
| Rated Current | 15A |
| Instantaneous Current | Up to 30A |
| Rated Voltage | 500V DC |
| Contact Material | Gold-Plated Brass |
| Housing Material | Heat-Resistant Polyamide Nylon |
| Contact Resistance | Approximately 0.70 mΩ |
| Recommended Wire Size | 18 AWG nominal |
| Operating Temperature | −20°C to 120°C (−4°F to 248°F) |
| Connection Method | Solder-On |
Package Includes
- 1 × XT30U male connector
- 1 × XT30U female connector
Total: One complete male and female connector pair.
Installation Notes
- Confirm connector polarity before soldering.
- Slide appropriately sized heat-shrink tubing onto the wire before soldering.
- Pre-tin the wire and connector solder terminals.
- Use a properly heated soldering iron to complete the joint quickly and avoid overheating the connector housing.
- Allow the connector to cool completely before installing the heat-shrink tubing.
- Insulate each solder joint separately to prevent a short circuit.
Important: Always verify polarity before connecting a battery. Reversed polarity may damage the battery, ESC, charger, or other electronic equipment.
Heat-shrink tubing, wire, battery, ESC and other installation components are not included unless specifically shown or stated elsewhere in the listing.
