Gens ace G-Tech 2200mAh 3S 60C LiPo Battery with EC3 Plug

Gens ace G-Tech 2200mAh 3S 60C LiPo Battery with EC3 Plug

Power your compatible RC airplane, helicopter, glider or FPV model with the Gens ace G-Tech 2200mAh 3S LiPo battery. It combines an 11.1V configuration, 60C continuous discharge rating and EC3 main connector in a compact soft-case battery pack.

The integrated G-Tech system allows a compatible G-Tech charger to identify the battery and automatically communicate its charging parameters. The battery may also be charged with a conventional LiPo balance charger when the correct settings are entered manually.

G-Tech Features

• Automatic battery identification with compatible G-Tech chargers
• Communicates battery information to the charger
• Helps configure the appropriate charging parameters
• Can also be used with a suitable conventional LiPo balance charger

Battery Features

• 2200mAh minimum capacity
• 11.1V nominal voltage
• 3S1P three-cell configuration
• 60C continuous discharge rating
• 120C maximum burst discharge rating
• Preinstalled EC3 main connector
• G-Tech smart balance connector
• 12 AWG discharge wires
• Soft-case construction

Specifications

• Battery type: Lithium polymer (LiPo)
• Capacity: 2200mAh
• Nominal voltage: 11.1V
• Cell configuration: 3S1P
• Energy: 24.42Wh
• Continuous discharge rate: 60C
• Maximum burst discharge rate: 120C
• Maximum charge rate: 5C (11A)
• Main connector: EC3
• Balance connector: G-Tech smart connector
• Wire gauge: 12 AWG
• Discharge-wire length: Approximately 4.72 inches (120 mm)
• Dimensions: Approximately 4.28 × 1.34 × 0.91 inches (108.8 × 34 × 23 mm)
• Weight: Approximately 6.53 oz (185 g)
• SKU: GEA223S60E3GT
• Manufacturer part number: GA-B-60C-2200-3S1P-EC3-GT
• UPC: 889551117241

Package Includes

• 1 × Gens ace G-Tech 2200mAh 3S 60C LiPo battery with EC3 connector

Compatibility

This battery may be suitable for compatible RC airplanes, gliders, FPV models and 450-size helicopters. Battery selection must be based on your model’s required voltage, connector, dimensions, weight and discharge requirements.

Before ordering: Confirm that your model uses an EC3 connector and has sufficient battery-compartment space. EC3 and IC3 connectors are related designs but should not be represented as the same connector.

LiPo Battery Safety

Use only a charger designed for lithium-polymer batteries. Select the correct cell count, chemistry and charging current. Never charge a LiPo battery unattended. Inspect the battery before each use and discontinue use if it becomes swollen, punctured or otherwise damaged. Charge and store the battery in a suitable fire-resistant LiPo container.
