SunnySky X7025 V3 190KV Brushless Airplane Motor – 40cc Equivalent
The SunnySky X7025 V3 190KV is a brushless electric airplane motor in the 40cc-equivalent power class. Designed for compatible fixed-wing RC aircraft, it is an option for giant-scale electric builds and gas-to-electric conversions.
The 190KV version has a manufacturer-listed maximum power of 5,800 watts and weighs approximately 27.69 oz (785g), including wires. Match the motor with an appropriate battery, ESC, and propeller for your aircraft and flying requirements.
Key Features
- 190KV winding: This listing is specifically for the X7025 V3 190KV motor.
- 40cc-equivalent power class: An electric power option for compatible aircraft in this class.
- Brushless electric operation: Suitable for new electric builds and compatible gas-to-electric conversions.
- 5,800W listed maximum power: Actual power and current draw depend on the complete power system.
- 24N22P configuration: Features 24 stator slots and 22 rotor poles.
- 10mm shaft diameter: Confirm compatibility with your propeller mounting hardware.
Specifications
| Brand | SunnySky |
|---|---|
| Model | X7025 V3 |
| Motor Type | Brushless electric airplane motor |
| KV Rating | 190KV |
| Equivalent Power Class | 40cc |
| Stator / Rotor Configuration | 24N22P |
| Internal Resistance | 15.06 mΩ |
| Motor Length | 2.64 in (67mm) |
| Shaft Diameter | 0.394 in (10mm) |
| Motor Weight Including Wires | 27.69 oz (785g) |
| Manufacturer-Listed Maximum Power | 5,800W |
| Manufacturer-Listed Current Limit | 127A for 30 seconds |
| Recommended ESC Current Rating | 130A; ESC voltage rating must match the battery system |
| Suggested Propeller Sizes | 21 × 10, 22 × 10, and 22 × 14 in |
Aircraft Fit and Installation
Before installation, confirm motor dimensions, mounting compatibility, propeller clearance, and the aircraft's recommended power requirements. For a gas-to-electric conversion, account for the weight and placement of the motor, ESC, and batteries when setting the aircraft's center of gravity.
The 40cc-equivalent designation identifies a general power class. Aircraft suitability depends on model weight, flying style, and the selected electric power system.
ESC and Propeller Selection
SunnySky lists a 130A ESC recommendation and suggested propeller sizes of 21 × 10, 22 × 10, and 22 × 14 inches for the 190KV version. Select an ESC with a voltage rating appropriate for your battery system.
Propeller load varies with battery voltage and propeller design. Use the suggested sizes as starting points, then measure current draw with your actual setup. Provide adequate cooling and keep the motor, ESC, and battery within their operating limits. The listed 127A rating is limited to 30 seconds and should not be treated as a continuous operating rating.
